Battery Tab Welder
Provide you with Battery Tab Welders with Advanced Welding Functions as well as low cost solutions.
Welders designed for superior battery tab welding
Lower prices on equipment and electrodes than other manufacturers
Shorter lead time, especially on electrodes
Free test welds and unparalleled customer support
Parallel Gap Spot Welding
How We Can Help You
Advanced Integrated Technologies ( AIT ) offers you free test welds to help determine if an inverter welder is the proper equipment for your application. Â We are a equipment and technical support provider for Nippon Avionics ( Avio ) brand of precision inverter welders. Â At AIT, we have chosen the AVIO line of equipment because you get more advanced technology, quality, and precision for your money than with other popular brands. Â We can provide the equipment you need at an economical price, and assist with any technical issues you encounter setting up your welding process. Â Submit a contact form or call us today to request assistance with your next project.
Click here for matching weld heads.
Click here for matching weld heads.
AVIO Battery Tab Welder.
- Designed for series welding of battery tabs without damaging battery cells
- Fast rising time equaling less thermal damage
- Polarity switch function leading to uniform welds and longer electrode life
- 4 pulse wave form with pre-weld
- Automatic weld stop function to preven over energy welds
- LCD graph of welding wave form
Click here for matching weld heads.
| Features | Specifications | |
| Welding Power Supply | NRW-PS300 | |
| Welding Transformer | NT-PS300 | |
| Control Method | IGBT Control (Polarity Switch) | |
| Secondary Short-Circuit Current | 8000A | |
| Maximum Output Power | 300ws | |
| Setting Range | Weld Time | total 0.0 - 60.0ms |
| Transformer Tap | 2.5V, 5.0V, 7.1V, 10.0V | |
| Number of Condition | 63 | |
| Monitoring | V, I, W, R (Average, Peak)Â ws (phase shift) | |
| I/O Interface | I/O Connector (50pin), EXT_I/O (12pin) | |
| Communication | RS232C | |
| Power Source | 380-415V ACÂ +/-10% | |
Effect of Polarity Switch Function
Without
With
Various welding modes for stable welding
Example of 4 pulse welding schedule
Battery Pack Welding
Transformer NT-PS300 & Power Supply NRW-PS300
Graphic Display of Welding Wave Form
| Other Transformer Options | ||
| Features | NT-PS1500 | NT-PS1500H |
| Secondary Short-Circuit Current | 8000A | 8000A |
| Maximum Output Power | 1500 ws | 1500 ws |
| Transformer Tap | 2.5V, 5.0V, 7.1V, 10.0V | 10.0V, 14.1V, 20.0V, 28.3V |
| Weight | 52kG | 53kG |
